Perfect Laser-20W 30W 50W 100 Watts Metal Stainless Steel Brass Ipg/Raycus/Max/Jpt/Mopa Wuhan Fiber CNC Laser Marker Engraving Marking Etching Machines Price

Basic Info

Model NO.	PEDB-400D
Laser Wavelength	Fiber Laser
Laser Classification	Solid Laser
Type	Optical Fiber Laser Marking Machine
Marking Method	Scanning Marking
Product Name	3D Fiber Laser Marking
Control	Automatic
Current	AC
Pulse Repetition Rate* kHz	20-80 kHz
Operating Voltage	220V
Max. Power Consumption	600W
Net Weight	130 Kgs
Scanning Speed	0-7000mm/S
Marking Speed	0-5000mm/S
Marking Size	110mm×110mm (F-Theta 160)
Transport Package	Export Sea-Worthy Packing or Air-Worthy Packing
Specification	143*62*101cm
Trademark	Perfect Laser
Origin	China
HS Code	8456110090
Production Capacity	5000 Sets/Year

Product Description

Perfect Laser-20w 30w 50w 100 Watts Metal Stainless Steel Brass IPG/Raycus/MAX/JPT/Mopa Wuhan Fiber CNC Laser Marker Engraving Marking Etching Machines Price
(Model: PEDB-400D)
Product DescriptionPerfect Laser's Laser Marking Machines PEDB-400D adopts international most advanced technology and the laser source is fiber with USA IPG technology, lifetime can reach 100, 000 hours, 8-10 years without any consumables and maintenance.The upright column can adjust the height of the laser head, which can help to mark the work piece with different shape and thickness.The diode coupling with fiber to process pump, the pump light will course the particles reverse which can emit high quality laser beam.This is the best choice for the customers who have special requirements to the smallest & finest laser beam and character.



ApplicationThis Laser Marking Machines is widely used in mobile button, plastic transparent button, electronic parts, IC, tools, communication products, bathing products, tool accessories, glasses and watches, jewelry, button decoration for boxes and bags, cookers, stainless steel products and so on.
Product Features1.Best Marking Effect: the laser beam of 20w 30w Fiber Laser is fine and thin. It can provide the best marking effect among all the laser machines. Especially good at smallest character marking, such as mark on IC chip.2.Deep Marking: Perfect Laser's ytterbium fiber laser can make deep marking up to 1.0mm on stainless steel and aluminum. While YAG and Diode marking only could mark 0.2mm-0.3mm. 3.Higher Accuracy: fiber laser can reach unto 0.001mm precision, while diode only 0.01mm.4.10 Years Long lifetime: The fiber laser module is made by Germany IPG technology, the lifetime can reach 100,000 hours, enable 8-10 years using of the machine.5. No consumables: 30w fiber laser marking system can be used for 8-10 years without any consumables. 6.No need to adjust the laser path.7.Free of Maintenance.8.Use Integrated air ccoling.9.Low Power Consumption: low cost, only 0.5kw/hour. 10. Small and compact: the volume of Perfect Laser's fiber laser marking machine is small, only 0.15 M3.



Technical Data

Machine Type	Fiber Laser Marking Machine
Laser Sourse	PEDB-400B 10W		PEDB-400B 20W
IPG Series	Pulsed, High Energy Ytterbium Fiber Lasers
Mode of operation	Pulsed
Polarization	random
Q-switched operation
Output power adjustment range	10%-100%
Nominal average output power W	10W		20W
Central emission wavelength	1060-1070 nm
Emission Bandwidth (FWHM)	<10 nm
Long-term average power instability	<5%
Pulse width, (FWHM)	100 ns
Laser switching ON time	180 μsec
Laser switching OFF time	180 μsec
Pulse Repetition Rate* kHz	20-80 kHz
Energy per pulse (PRR = 20 kHz)	0.95 mJ
Typical beam quality, M2	<1.8
Output fiber delivery length	3m
Operating voltage	220V
Max. Power consumption	600W

Our service1> All of our machine will be full-checked by our quality control department before the shipment. We make sure that customers will be get good products from us and all of our machine with a 12 months quality guarantee period.2> We will enclose an "Instruction Book", "Operation Manual" and "Training Video" (in English version) to you, which is easily understood and handle by the customer.3> We will offer plenty of online supports, by Skype, whatsapp, email, video, telephone and fax. 4> Our engineer can make a door-to-door instruction training service.



Company informationWe, Perfect Laser, As a 21 years history industrial equipment manufacture in laser field, 12 year Golden Supplier in Alibaba, with CE/ISO/FDA, we aims to make high quality products, and also our products have been exported to more than 180 different countries and areas.
